| Paraiméadar | |||||
| Mír UIMH | K18-UP500D56+24 | ||||
| Aschur | Voltas Aschuir | V1: +56VDC; V2: +24VDC | |||
Rátáilte Reatha | V1:8A; V2:2A | ||||
Raon Reatha | V1:0.1-8A V2:0.1-2A | ||||
Cumhacht Rátáilte | 496W | ||||
Ripple& Torann | V1: 560mVp-p; V2: 240mVp-p | ||||
Raon Aschuir Inchoigeartaithe | V1:+/-5% | ||||
Cruinneas Aschuir | V1:±1% ;V2:+/-5% | ||||
Rialachán Líne | V1:±0.5% ;V2:+/-1% | ||||
Rialachán Luchtaithe | V1:±0.5%; V2: +/-4% | ||||
Cuir ar bun, Éirigh, Coinnigh suas am | 500ms, 50ms, 5ms / 115VAC 200ms, 50ms, 5ms / 230VAC | ||||
| Ionchur | Raon Voltais Ionchuir | 90 ~ 264VAC | |||
Ionchur Reatha | 5A/115V,2.5A/230V | ||||
Minicíocht Ionchuir | 47 ~ 63Hz | ||||
Éifeachtacht | & gt; 93% @ 230V | ||||
| Fachtóir Cumhachta | 95% @ 230VAC, 99% @ 115VAC | ||||
Inrush Reatha | Tús fuar 30A / 230VAC, 15A @ 115VAC | ||||
Sceitheadh Sceite | & lt; 0.5mA@240V | ||||
| Cosaint | Cosaint ar Luchtú | 110 ~ 160%, Cosaint Hiccup, aisghabháil uathoibríoch | |||
Cosaint Chuarda Ghearr | Cosaint Hiccup, admháil uathoibríoch. | ||||
| Cosaint ró-voltais aschuir | CH1: 65-70V | ||||
Cosaint ró-theocht | Cosaint N2 ＞ 105 ℃, aisghabháil uathoibríoch | ||||
Comhshaol | Temp Oibre, Bogthaise | -20 ~ 60 ℃, 10 ~ 90% RH, Gan aon chomhdhlúthú | |||
Temp Stórála, Bogthaise | -20 ~ 85 ℃, 10 ~ 95% RH | ||||
Temp., Drift | ±0.03%/℃(0~50℃) | ||||
Chreathadh | 10 ~ 500Hz, 2G 10min / 1cycle, LINN DO 60 nóiméad GACH AXES | ||||
Sábháilteacht& Caighdeáin EMC | Caighdeáin Sábháilteachta | GB4943, EN60950-1 | |||
Voltage a sheasamh | I / PO / P: 3KV; I / P-FG: 1.5KV; O / P-FG: 0.5KV AC | ||||
Friotaíocht Inslithe | I / PO / P, I / P-FG, O / P-FG: 500VDC / 100M Ohms | ||||
Caighdeáin EMC | EN55022 CLASSB, EN61000-3-2 | ||||
| Daoine eile | Toise | 127 * 82 * 48mm (L * W * H) | |||
| Meáchan | 0.5kg | ||||
| MTBF | & gt; 50 uair | ||||
